CAME - KIT AUTOMATION STYLO 8K01MB-015, TESTED IN ACCORDANCE WITH EN 12453-EN 12445
COMPLETE SYSTEM FOR SWING GATES UP TO 1.8 METRES PER LEAF WITH 24V DC MOTOR
MAXIMUM LEAF WEIGHT 100 KG
KIT STYLO
8K01MB-015
24V DC
IT INCLUDES:
- 2 STYLO-ME: Irreversible gearmotor with encoder for leaves up to 1.8 m, 24V DC
- 2 STYLO-BS: Articulated transmission arm
- 1 801QA-0050: Multifunctional control panel, with programming and signalling diplay, self-diagnosis of safety devices, Adaptive Speed & Torque Technology, CXN BUS, 2 safety inputs and storage for up to 250 users.
- 1 AF43S: 433.92 MHz plug-in radio frequency card
- 1 806TS-0270 TOP44RBN: 4-channel rolling code transmitter 433,92 MHz
- 1 DIR10: Pair of infrared photocells for outdoor mounting with 10 m range
- 1 806LA-0020: Led flashing light with power supply from 24 v ac - dc up to 230 v ac, with double built-in antenna (433.92 mhz and 868.35 mhz), with white dome
- 1 TOP-RG58: Antenna cable 5 Mt
- 1 Gate sign
